Introducing the XM CNC Fiber Laser Cutter, a powerful and efficient cutting machine from Liaocheng Xianming. With options of 1000w, 2000w, or 3000w power output and size variants of 1530 or 3015, this metal cutter fiber optic laser cutting machine is perfect for cutting steel plates and pipes with precision and accuracy
The XM CNC Fiber Laser Cutter is equipped with state-of-the-art fiber optic laser technology, allowing for fast and precise cutting of various metal materials. Whether you are working on thin steel sheets or thick steel plates, this machine delivers clean and smooth cuts every time. Say goodbye to rough edges and uneven cuts with the XM CNC Fiber Laser Cutter
Not only does the XM CNC Fiber Laser Cutter offer high cutting speeds and exceptional accuracy, but it is also versatile and easy to operate. The user-friendly interface and intuitive controls make it easy for operators to program and adjust cutting parameters, ensuring optimal results with every use. Whether you are a seasoned professional or a beginner in the industry, you will appreciate the simplicity and efficiency of the XM CNC Fiber Laser Cutter
In addition to its performance and ease of use, the XM CNC Fiber Laser Cutter is also designed with durability and reliability in mind. Built with high-quality components and a sturdy frame, this machine is built to last and withstand the demands of heavy-duty industrial applications. You can trust the XM CNC Fiber Laser Cutter to deliver consistent results day in and day out, helping you increase productivity and efficiency in your workshop
The XM CNC Fiber Laser Cutter is a top-of-the-line cutting machine that offers precision, speed, and reliability for all your metal cutting needs. Whether you are working on steel plates, pipes, or other metal materials, this machine will exceed your expectations and help you achieve superior results. Invest in the XM CNC Fiber Laser Cutter today and take your cutting capabilities to the next level
Model | XM-FM Series | |
Control System | Cypone/ CypCut-Friendss | |
Drives and Motors | Japan Fuji Servo Motor System | |
Fiber Laser Head | Raytools Laser Head | |
Fiber Source | Raycus or Max or IPG | |
Lubrication System | Electrical Motored | |
Guide Rails | Taiwan HIWIN Rails | |
Rack and Gear | Taiwan YYC Rack | |
Driver system power | X-750W, Y=750W, Z=400W, /X=1.3kW, Y=1.3KW, Z=400W | |
Reducer | apan SHIMPO | |
Electron Component | DELIXI ELECTRIC | |
Chiller | Haili/S&A | |
Voltage | 220V1Ph or380V3Ph, 50/60Hz | |
Gross weight | 1.9T | |
Optional Configuration | ||
Model | Detail | |
Control System | CypCut | |
Drives and Motors | Yaskawa Servo Motor System | |
Fiber Laser Head | RAYTOOLS BM110 Automatic Focus Laser Head | |
Stabilizer | Made in Chinia | |
Exhaust fan | 3KW | |
Wooden packing | With metal bracket |
Technical Parameters | ||
Mode | XM-FM 3015 FiberLaser Cutting Machine | |
Working Size | 1500*3000mm | |
Laser Power | 1/1.5/2/3/4/6/8/12KW | |
Laser Wavelength | 1080nm | |
Laser Beam quality | <0.373mrad<> | |
Working Life of Fiber Source | More than 10,0000 hours | |
Position Type | Red Dot Pointer | |
Cutting Thickness | 0.5-10mm Within The Range Standard Precision | |
Max. Idle Running Speed | 80-110M/min | |
Max acceleration | 1G | |
Reorientation Accuracy | Within+0.01mm | |
Lubrication System | Electrical Motored | |
Cooling mode | Water cooling and protection system | |
Machine power | 9.3KW/13KW/18.2KW/22.9KW | |
Auxiliary Gas for Cutting | Oxygen, Nitrogen, Compressed Air | |
Compatible Software | AutoCAD, CorelDraw, etc | |
Handle Control | Wireless Control Handle | |
Graphic Format | DXF/PLT/AI/LXD/GBX/GBX/NCcode | |
Power Supply Voltage | 220V1Ph or 380V3Ph,50/60Hz | |
Warranty | 2 Years |
Yes, We will send you manual and guide vedio in English, it can teach you how to operatethe machine. lfyou still can not learn how to use it, we can help you by "Teamviewer"online helpsoft-ware.Or we can talk by phone, email or skype
Q3. How long is the delivery time?
For standard machines,it would be 3-5 days: For non-standard machines and customized machinesaccording to client's specific requirements,it would be 7 to 10 days
04. Quality Control:
The whole production procedure will be under regular inspection and strict qualitycontrol. The complete machine will be tested to make sure they can work very wellbefore being out of factory.Our machine passed CE Certificate, meet European andAmerican standard, were exported to morethan 100 Countries
Q5. Do you arrange shipment for the machines?
Yes dear esteemed customers, for FOB or CIF price, we will arrange shipment for you
